HOME >> PRODUCTS >>DOOH >>Mesh LED display Solution >> VM 15.62
Product Detail

VM 15.62

商品说明




商品参数

Parameters / specifications
Model No.K15.62 (outdoor Lmesh ED display)K25 (outdoor Lmesh ED display)K41.6-50 (outdoor Lmesh ED display)Customized
RGBFull colorFull coloFull coloFull colo
PixelPitchW15.62mm*H15.62mmW25mm*H25mmW41.6mm*H50mmCustomized
LEDs346 (1R1G1B)346 (1R1G1B)346 (2R2G2B)346 (option RGB Qty.)
Pixel configurationDIPDIPDIPDIP
Pixel density/㎡40961600480--
Visual angle(M)16M-47M25M-75M42M-125M--
Transparency36%40%60%36%~90%
Max/Avg./㎡400W400W400W400W
Working Avg./㎡200W200W200W200W
Panel size（mm）W1000*H500*D50mmW1000*H500*D50mmW1000*H500*D50mmW1000*H500*D50mm
Pamel resolution64*3240*2024*10--
ScanStaticStaticStaticStatic
Brigthness10000CD/㎡7000CD/㎡6000CD/㎡--
Refresh rae3840/1920Hz3840/1920Hz3840/1920Hz3840/1920Hz
EncapsulationOrganosiliconOrganosiliconOrganosiliconOrganosilicon
Ingress protectionIP65IP65IP65IP65
Grey color degree16bit16bit16bit16bit
Brightness level256 degree256 degree256 degree256 degree
Panel materialAluminum frame + LED stripAluminum frame + LED stripAluminum frame + LED strip条Aluminum frame + LED strip
Driver ICCINCINCINCIN
Control systemMooncell/NovaMooncell/NovaMooncell/NovaMooncell/Nova
Display connect portTerminal DIV/HDMITerminal DIV/HDMITerminal DIV/HDMITerminal DIV/HDMI
Power supplierMeanwellMeanwellMeanwellMeanwell
Input power voltageAC110~240V 50HzAC110~240V 50HzAC110~240V 50HzAC110~240V 50Hz
Working environment -20 ~ 50°C -20 ~ 50°C -20 ~ 50°C -20 ~ 50°C
InstallationFront&rear serviceFront&rear serviceFront&rear serviceFront&rear service
Warranty2 years2 years2 years2 years
LED lifetime100000 hours100000 hours100000 hours100000 hours
Cooling systemAluminum-self coolingAluminum-self coolingAluminum-self coolingAluminum-self cooling
Outline perfomanceAluminium alloy electrostatic spraying（color option）+ material PC UVAluminium alloy electrostatic spraying（color option）+ material PC UVAluminium alloy electrostatic spraying（color option）+ material PC UVAluminium alloy electrostatic spraying（color option）+ material PC UV
Panel weight9kg9kg8kg--
